Overview

Four classic ISA preamps with DI inputs and a premium eight-channel A-D converter option.

Focusrite's ISA mic preamps can be traced back to 1985, when console designer Rupert Neve was asked by Sir George Martin to create new modules for the console at AIR Montserrat. The modules he created included the legendary ISA110, on which all ISA microphone preamps are based. With their characteristic Lundahl LL1538 input transformer, along with one concession to modernity—variable input impedance—ISA mic preamps are very much the same as they were 30 years ago. But today, instead of solely gracing the consoles at AIR, ISA mic pres are at the heart of hundreds of hits made in leading studios and by leading engineers, artists and producers, across the world.

Now in its second generation, the ISA 428 MkII incorporates four of Focusrite's renowned mic pres in a simple-to-operate 2U enclosure, placing four mic preamps, instrument inputs and line ins at your fingertips. The original Focusrite mic pre was designed to suit the microphones of the time; today's model makes a small change, adding three additional input impedances to the classic ISA110 setting, allowing you to match any microphone, old or new, and access a wide range of sounds, from the character and warmth of a vintage mic to the clear transparency of a modern design. Or, you can experiment and bring out just the qualities you want.

In addition to the mic inputs, there are four front-panel instrument inputs, making the ISA428 MkII ideal for overdubs in the control room with no need for a DI box. On the back: four line inputs and switchable insert points on each channel to allow routing via external signal processors. There's also a versatile, vintage design variable high-pass filter to control what's going on at the bass end. And finally, accurate, 6-LED meters to tell you exactly what's going down. Optionally, available for the ISA428 MkII is a precision eight-channel A-D converter with 122dB dynamic range and superb jitter performance (sold separately)—ideal for simple interfacing with your DAW.

UPDATE: Now comes with Brainworx bx_console Focusrite plug-in
This awesome plug-in recreates the analog signal paths of Focusrite’s revered ISA 110 and ISA 130 modules, which were a part of the Focusrite Studio Console. Designed and coded by the DSP geniuses at acclaimed software house Brainworx, the new bx_console Focusrite VST/AU/AAX plug-in for Mac and PC faithfully captures the sound, feel and styling of the original iconic hardware.

If you purchased any Red, RedNet or ISA solution from January 2020 on, you will have the plug-in available in your Focusrite account as long as you’ve registered your product.

Features

Four ISA series transformer-based preamps
Eight-channel optional A-D converter
Selectable impedance
Four front panel instrument inputs
Dedicated analog insert points
Accurate LED meters for every channel
Focusrite offers a 2-year manufacturer's warranty

A great front end for your DAW—4 classic preamps plus an optional 8 channels of conversion—all at an amazing price. Order today!

Specs

ISA428 MKII 4-Channel Microphone Preamp Specifications:

Mic Inputs

Frequency response at minimum gain (0dB): –0.35dB at 20Hz and –3dB at 122kHz
Frequency response at maximum gain (60dB): –2.5dB at 20Hz and –3dB 103kHz
Gain range: 0dB to +60dB in 10dB steps, plus 0dB to +20dB continuously variable trim
Maximum headroom: +7.4dBu
THD+N: 0.0009% (measured at 1kHz –20dBu input signal, at 30dB gain setting, with a 20Hz/22kHz bandpass filter)
Noise EIN: –126dB (measured at 60dB of gain with 150 ohm termination and 20Hz/22kHz bandpass filter)
Noise at main output with unity gain: –98dBu (measured with a 20Hz/22kHz bandpass filter)
SNR: 123dB (relative to max output 25dBu)
SNR: 120dB (relative to 0dBFS (+22dBu)
CMRR: 88dB
Input Impedance, variable: 600 ohm, 1,400 ohm, 2,400 ohm, 6,800 ohm

Line Inputs

Frequency Response at unity gain (0dB): –0.3dB at 20Hz and –3dB at 94kHz
Gain range: –20dB to +10dB in 10dB steps, plus 0dB to +20dB continuously variable trim
Maximum headroom: +25.4dBu
THD+N: 0.002% (measured with +4dBu input signal, 0dB gain setting, with a 20Hz/22kHz bandpass filter)
Noise at main output with unity gain: –91dBu (measured with a 20Hz/22kHz bandpass filter)
SNR: 116dB (relative to max output 25dBu)
SNR: 113dB (relative to 0dBFS +22dBu). Input Impedance: 10 kohm
Instrument Inputs
Frequency Response at +10dB gain: -0.2dB at 20Hz and 0dB at 200kHz
Frequency Response at +40dB gain: -3dB at 20Hz and -3dB at 38.4kHz
Gain range: +10dB to +40dB continuously variable
Maximum headroom: +11.5dBu
THD+N: 0.006% (measured with -20dBu input signal, at minimum gain (+10dB), with a 20Hz/22kHz bandpass filter)
Noise at main output with minimum gain (+10dB): –95dBu (measured with a 20Hz/22kHz bandpass filter)
Input Impedance = >1 mohm

High Pass Filter

Roll off = 18dB per octave 3 pole filter
Frequency range: 16Hz to 420Hz (continuously variable, measured at the 3dB down point)

Meters

6 LED meter is calibrated 0dBFS = +22dBu (the maximum level which can be correctly converted by the optional internal A/D converter before overload occurs). The meter calibration points are as follows:
Meter panel calibration value in dBFS/equivalent dBu value
0dBFS/+22dBu
-2dBFS/+20dBu
-6dBFS/+16dBu
-12dBFS/+10dBu
-18dBFS/+4dBu
-42dBFS/–20dBu

Front and rear connectivity

Analog Channel Inputs (Inputs 1-4)
4 instrument 1/4" TS jack inputs on front panel
4 microphone XLR inputs on rear panel
4 line 1/4" TRS jacks on rear panel
4 insert return 1/4" TRS jacks on rear panel
4 ADC XLR inputs on rear panel

Analog Audio Outputs (Outputs 1-4)

4 line XLR outputs on rear panel
4 insert send 1/4" TRS jacks on rear panel

Other I/O

IEC power input connector 100Vac–240Vac
Front Panel Indicators
8 output meters, 6 segment
4 30–60 mic gain range selection indicator
4 +48V phantom power indicator
4 Phase indicator
4 Insert In indicator
4 Filter In indicator
4 Input selection indicators (Mic, Line, Inst)
4 Z In microphone input impedance selection indicators (Low, ISA110, Med, High) Clock select indicators (44.1, 48, 88.2, 96, 176.4, 192)
Ext. clock indicators (Lock, Word clock, 256X)
Weight: 12.2 lb. (5.5 kg)
Dimensions (WxHxD): 480 mm x 88 mm x 280 mm, 19" x 3-1/2" x 11"
