Overview

Designed for meeting-room full coverage of large tables.

The MX396 Tri-Element Boundary Microphone features three cardioid elements that are adjustable to 120-120-120 degrees, a mute output, and an LED input. The cable can exit from either the back or bottom exit of the unit. The Shure MX396 Tri-Element microphone is a unique and versatile tool for conference room installations, providing full coverage of large tables using fewer microphones, and a low profile design. Clean and simple in appearance, the MX396 boundary mic is ideal for use in boardrooms and other installations where aesthetics are important. The Shure multi-element plate microphone is also available in a dual element configuration.

Features

  • End of table (300 degrees ), center of table (360 degrees ), or cross table (bidirectional) coverage patterns
  • Low profile, aesthetic design
  • Wide dynamic range and smooth frequency response
  • Individual control of each element
  • Bi-color status indicator
  • Programmable mute switch
  • Logic input/output for remote LED and mute control
  • Radio Frequency filtering with CommShield technology
  • Configurable mute switch with logic output
Specs

MX396C Microflex Multi-Element Boundary Microphone Specifications:

  • Type: Condenser (electret bias)
  • Frequency Response: 50”17000 Hz
  • Polar Pattern: 3 x Cardioid
  • Output Impedance: EIA Rated at 150 Ohms (170 Ohms actual)
  • Output Configuration: Active balanced
  • Sensitivity (at 1 kHz , open circuit voltage): ”35 dBV/Pa (18 mV) 1 Pascal=94 dB SPL
  • Maximum Sound Pressure Level (1 kHz at 1% THD, 1 kohms load): 122 dB Equivalent Output Noise (A-weighted) 28 dB SPL
  • Signal-to-Noise Ratio (referenced at 94 dB SPL at 1 kHz): 66 dB
  • Dynamic Range (1 kohms load at 1 kHz): 94 dB
  • Common Mode Rejection (10 Hz to 100 kHz): 45 dB minimum
  • Preamplifier Output Clipping Level (1% THD): ”7 dBV (0.5 V)
  • Weight Net: 1.29 lbs. (0.587 kg)
  • Packaged: 2.02 lbs. (0.916 kg)
  • Logic Connections LED IN: Active low (?1.0V), TTL compatible. Absolute maximum voltage: -0.7V to 50V. LOGIC OUT: Active low (?1.0V), sinks up to 20mA, TTL compatible. Absolute maximum voltage: -0.7V to 50V (up to 50V through 3kohms).
  • Mute Switch Attenuation: ”50 dB minimum
